Model 106-SPI-MV Single Point Insertion Flow Metering Valve
With over 100 years of combined waterworks experience, Singer Valve and McCrometer have teamed up to provide a unique solution for in-valve flow measurement.
Find a Singer Valve Rep Near You
With over 100 years of combined waterworks experience, Singer Valve and McCrometer have teamed up to provide a unique solution for in-valve flow measurement. Using McCrometer’s proven Single Insertion Meter technology along with the reliability of a Singer Valve, it allows users to have both a flow meter solution along with any function of control valve.
Whether it is pressure reducing, level control, or sustaining - all can be installed now with a very accurate flow meter solution.
The Singer Model 106-SPI-MV is a Single Point Insertion Electromagnetic Flow Meter, installed and calibrated in conjunction with a Singer Valve to provide an accurate flow rate. This cost effective flow meter option is available for valve sizes from 4” (100mm) to 36” (900mm). With no moving parts and a single-piece design, the SPI Mag’s sensor contains nothing to wear or break, and it is generally immune to clogging by sand, grit or other debris. The 106-SPI-MV Mag is profiled for the valve body, further enhancing its measurement accuracy by allowing precise determination of mean velocities. The flow sensor comes pre-calibrated from McCrometer’s NIST traceable Calibration Lab and requires no recalibration in the field.
The meter can be installed with any standard Singer pilot system or combined with the 2SC-PCO to provide complete flow based valve control.
